Command Bar
The area on the upper part of the main window where function icons are arranged is called the "Command Bar". Clicking an icon on the [Command Bar] is equivalent to executing a menu function.
|
Select the [File] menu > [Command Bar Settings] to customize the items that appear on the [Title Bar]. For details, see "Command bar settings [Windows] [PRO/EX]". [PRO/EX] |
When using Windows/macOS
![503_pallet_0036.jpg](503_pallet_0036.jpg)
(1) Open CLIP STUDIO
The included portal application “CLIP STUDIO” will launch.
|
CLIP STUDIO is a tool for supporting creative activities. |
(2) New
Creates a new canvas necessary for creating an illustration.
(3) Open
Opens a saved illustration or image for re-editing.
(4) Save
Saves an illustration or image being created.
(5) Undo
Clicking it cancels the last operation.
(6) Redo
Clicking it redoes the undone operation.
(7) Delete
Deletes everything drawn on a layer. When there is a selection, deletes everything within the selected area.
(8) Delete Outside Selection
Deletes everything outside the selected area.
(9) Fill
Fills in the selected color. When there is a selection, fills the selected area.
(10) Scale/Rotate
Scales up/down, rotates, or transforms. When there is a selection, scales up/down, rotates or transforms the content of the selected area.
(11) Deselect
Deselects a selected area.
(12) Invert selected area
Inverts a selected area.
(13) Show border of selected area
Displays/hides the dashed line indicating a selected area.
(14) Snap to Ruler [PRO/EX]
Configures snap to ruler. When turned on, allows you to draw along a ruler.
(15) Snap to Special Ruler [PRO/EX]
Configures snap to special ruler. When turned on, allows you to draw along a special ruler.
(16) Snap to Grid [PRO/EX]
Configures snap to a perspective ruler grid. When turned on, allows you to draw along the grid lines of a perspective ruler.
(17) CLIP STUDIO PAINT Support
The web browser opens to the support page for Clip Studio Paint.
|
In DEBUT, an icon that introduces Clip Studio Paint PRO functionalities is displayed. Clicking the icon opens the Web browser to display a Web page that introduces functions available after upgrading to Clip Studio Paint PRO. |
When using a Tablet
![503_pallet_0048.jpg](503_pallet_0048.jpg)
(1) Display the application menu
Display the application menu and select it.
(2) Use different tools with fingers and pen
Switch between using the current tool or the tool assigned as a touch gesture when swiping with one finger.
·When turned on, swiping with one finger will operate the tool defined in the [Modifier Key Settings] dialog. The [Hand] tool will be assigned by default.
·When this is turned off, the screen can be swiped with one finger to operate the selected tool.
(3) Open CLIP STUDIO
The [CLIP STUDIO] dialog box opens. CLIP STUDIO is a tool for supporting creative activities.
(4) New
Create a new canvas necessary for a new piece of work.
(5) Open
Opens a saved illustration or image for re-editing.
(6) Save
Saves an illustration or image being created.
(7) Undo
Clicking it cancels the last operation.
(8) Redo
Clicking it redoes the undone operation.
(9) Delete
Deletes everything drawn on a layer. When there is a selection, deletes everything within the selected area.
(10) Delete Outside Selection
Deletes everything outside the selected area.
(11) Fill
Fills in the selected color. When there is a selection, fills the selected area.
(12) Scale/Rotate
Scales up/down, rotates, or transforms. When there is a selection, scales up/down, rotates or transforms the content of the selected area.
(13) Deselect
Deselects a selected area.
(14) Invert selected area
Inverts a selected area.
(15) Show border of selected area
Displays/hides the dashed line indicating a selected area.
(16) Snap to Ruler
Configures snap to ruler. When turned on, allows you to draw along a ruler.
(17) Snap to Special Ruler
Configures snap to special ruler. When turned on, allows you to draw along a special ruler.
(18) Snap to Grid
Configures snap to a perspective ruler grid. When turned on, allows you to draw along the grid lines of a perspective ruler.
(19) CLIP STUDIO PAINT Support
The web browser opens to the support page for Clip Studio Paint.
